Highlights
HD Filter
DuraFin+
Good Night Sleep
Features
Reduces energy use
Energy Saving
Save money every day with digital inverter technology. It maintains the desired temperature without frequently turning off and on, so there’s less fluctuation. And it uses strong magnets and a Muffler, so it is quieter, lasts much longer and reduces energy consumption.
Cools you faster
Fast Cooling
Cool a whole room rapidly and effectively. Fast Cooling mode operates with the fastest fan speed, before slowing down. So it cools or heats much faster compared to the normal mode* and reaches the desired temperature in the shortest time. It’s ideal for immediate relief from the heat outside.
Breathe purer air
HD Filter
Make sure that the air you breathe is always clean and fresh. The HD Filter is really effective at capturing dust, airborne contaminants and allergens, such as pollen, mold spores and pet dander. And it’s also washable, so all you need to do is give it a quick rinse in water and then reuse it.
Enjoy a good sleep
Good Sleep
Enjoy a great night’s sleep – every night! Good Sleep mode automatically controls and fine-tunes the temperature to create the ideal conditions for each stage of the sleep cycle. So you gain precious minutes of sleep and feel fully refreshed. And it also uses less energy than normal cooling.
Cools every corner
2-Way Auto Swing
Create a comfortable environment with an even temperature in every corner. The 2-Way Auto Swing function automatically controls the air flow direction, so it’s quickly and evenly distributed across the room. It can expel cool or warm air further and in every direction to ensure maximum comfort.
Long-lasting cooling
DuraFin+
Stay comfortably cool for much longer. The DuraFin+ is made of corrosion-resistant material to protect the condenser from rusting, which helps to maintain the optimal performance of the Heat Exchanger. Its superb corrosion-resistance was proven using the Salt Spray Test (SST) for 480 hours*.
* Tested on the AR12TXFCAWKNEU, AR13TYHYAWKNST model.
Specifications
-
Capacity (Cooling, Btu/hr)
24000 Btu/hr
-
Capacity (Cooling, kW)
7.03 kW
-
EER (Cooling, W/W)
3.21 W/W
-
Net Dimension (Outdoor, WxHxD, mm)
958×660×402 mm
-
Capacity (Cooling, Btu/hr)
24000 Btu/hr
-
Capacity (Heating, Btu/hr)
24000 Btu/hr
-
Capacity (Cooling, Min - Max, Btu/hr)
5,460-28,230 Btu/hr
-
Capacity (Heating, Min - Max, Btu/hr)
5,450-27,000 Btu/hr
-
Capacity (Cooling, kW)
7.03 kW
-
Capacity (Heating, kW)
7.03 kW
-
Capacity (Cooling, Min - Max, kW)
1.60-8.30 kW
-
Capacity (Heating, Min - Max, kW)
1.60-7.90 kW
-
EER (Cooling, W/W)
3.21 W/W
-
COP (Heating, W/W)
3.60 W/W
-
EER (Cooling, Btu/hW)
10.95 Btu/hW
-
COP (Heating, Btu/hW)
12.28 Btu/hW
-
Energy Efficiency Class for cooling (Grade)
A (Heating : A+)
-
Noise Level (Indoor, High/Low, dBA)
45.5/35 dBA
-
Noise Level (Outdoor, High/Low, dBA)
53 dBA
-
Power Source(Φ/V/Hz)
1 / 220-240 / 50
-
Power Consumption(Cooling, W)
2191 W
-
Power Consumption(Heating, W)
1954 W
-
Operating Current(Cooling, A)
9.8 A
-
Operating Current(Heating, A)
8.9 A
-
Gross Dimension (Indoor, WxHxD, mm)
1148×413×350 mm
-
Gross Dimension (Outdoor, WxHxD, mm)
1032×737×456 mm
-
Net Dimension (Indoor, WxHxD, mm)
1078×325×246 mm
-
Net Dimension (Outdoor, WxHxD, mm)
958×660×402 mm
-
Gross Weight (Indoor, kg)
20.0 kg
-
Gross Weight (Outdoor, kg)
47.5 kg
-
Net Weight (Indoor, kg)
17.0 kg
-
Net Weight (Outdoor, kg)
43.0 kg
-
Loading Quantity (20/40/40Hft without Pipe)
56/119/134
-
Piping Length (Max, m)
25 m
-
Piping Height (Max, m)
10 m
-
SVC Valve (Liquid (ODxL))
φ6
-
SVC Valve (Gas (ODxL))
φ16
-
Moisture Removal (l/hr)
2.50 l/hr
-
Air Circulation (Cooling, ㎥/min)
1250 ㎥/min
-
Refrigerant (Type)
R410A
-
Refrigerant (Charging, kg)
1.50 kg
-
Low Ambient (Cooling, ℃)
18~48 ℃
-
Low Ambient (Heating, ℃)
-7~24 ℃
-
Air Direction Control (Up/Down)
Auto
-
Air Direction Control (Left/Right)
Manual
-
Air Flow Control Step (Cool/Fan)
3 Step
-
Easy Filter Plus (Anti-Bacteria)
No
-
Auto Clean (Self Cleaning)
No
-
SmartThings
No
-
AI Auto Cooling
No
-
Motion Detect Sensor
No
-
Freeze Wash
No
-
Filter Cleaning Indicatior
No
-
Indoor Temp. Display
Yes
-
Display On/Off
Yes
-
Beep On/Off
No
-
24-Hour Timer
Yes
-
Auto Changeover
No
-
Auto Restart
Yes
-
Auto Mode
Yes
-
Fast Cool
Yes
-
Good Sleep
Yes
-
Dehumidification
Yes
-
Fan Mode
Yes
-
Quiet
No
-
WiFi Embedded
No
-
SmartThings App Support
No
